Why MCPTT?

Although conventional voice-oriented push to talk radio solution can provide mature audio communication and slight amount data service, LTE technology reveals the possibility of multi-media content exchanging. Feature-rich information can improve the efficiency and safety of first responders drastically.

Who needs MCPTT?

Public safety entities, such as police, fire, and EMS(Emergency Medical Services) organizations and those who require instant and reliable communication for saving lives and properties management.

Rescue

Fire Fighter

Police

Government

What constitute MCPTT?

1. Quite amount of entities are keeping research on public safety communication and providing MCPTT services co-operatively. To deploy an MCPTT solution, MC network, MC services and MC UEs are necessary.

  • MCPTT UE

  • MCPTT Service

  • MCPTT Network

MCPTT VS PoC

Network

Terminal Hardware Requirements

QoS

Call setup latency

Radio Resource Occupation

Targeting Market

MCPTT LTE 3GPP MC features supported by chipset Yes Low Can be reduced by eMBMS technology Public Safety Entities
PoC 2G, 3G, LTE Not require chipset support No High Each terminal has an individual bearer and bandwidth occupation Commercial Markets

Telox MCPTT Terminals

  • High Priority

    Telox MCPTT terminals support MCPTT QoS Class identifiers to improve availability and reliability of push-to-talk service. Mission critical voice communication is always prioritized and never be interrupted.

  • Multi-cast

    Benefited from LTE multi-cast technology, MCPTT terminals have significant improvement in radio efficiency, especially when radio frequency resource is limited or the amount of radio units is massive.

  • Professional Radio Design

    Secured audio jack, high level protection, textured large PTT button, crystal clear speaker and multiple programmable keys make Telox MCPTT terminals fully utilizable as professional two way radios.

  • Various Accessories

    Effecient and constant communication is ensured with diversified accessories, include chargers, batteries, headsets, remote microphone speakers, carry solutions, etc.

Specifications

TE620P

  • Physical Characteristics
    Specifications
  • Dimension
    144mmx66mmx24.2mm (L*W*D)
    5.66 in x 2.60 in x 0.95 in
  • Weight
    282 g (10 oz)(with Battery)
  • Environmental
    Specifications
  • Dust And Water Intrusion(Ingress Protection)
    IP68
  • Drop Test
    1.5m
  • Operating Temperature
    -25°C to +60°C
  • Storage temperature
    -40°C to +80°C
  • Platform/ Hardware
    Specifications
  • OS
    Android Q
  • OS
    Android Q
  • Processor
    Octa-core processor; up to 2.2GHz; 64 bit processor
  • Memory
    3GB RAM
    32GB Internal Storage
    Storage is expandable with external 128 GB
    microSD™ card
    Optional 4GB RAM + 64GB Internal Storage
  • Screen
    4-inch 640*1136 HD IPS,
    scratch-resistant and durable glass
  • Touch Panel
    5 points Capacitive,G+FF,
    support wet finger, glove operation
  • Camera
    13MP Rear + 5MP Front
  • Batter
    5000 mAh, Li-Polymer, Removable
  • Sensor Platform
    Gravity Sensor
    Ambient Light Sensor
    Proximity Sensor
    Gyroscope
    Geomagnetic Sensor
    Acceleration Sensor
  • Connectivity
    Specifications
  • Cellular Network
    Global:
    LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28a/B28b
    LTE-TDD: B38/B39/B40/B41
    WCDMA: B1/B2/B4/B5/B8
    American:
    WCDMA: B2/B4/B5
    LTE-FDD: B2/B4/B5/B7/B12/B13/B14/B17/B25/
    B26/B66/B71
    LTE-TDD: B41
  • VoLTE, ViLTE & VoWiFi
    Support
  • PTT
    Support PTT apps & MCPTT QCI's 65, 66,69 &70
  • 3GPP Release
    Rel 12①
  • WLAN
    IEEE 802.11 a/b/g/n/ac, 2.4/5GHz
  • Bluetooth
    5.0 + LE +BR/EDR
  • Location
    GPS/GLONASS/BEIDOU and AGPS
  • NFC
    Support
  • Man Machine Interface
    Power Button
    Dedicated PTT Button
    Talkgroup Switch Knob
    Volume (Up / Down) Buttons
    Programmable Button X 2
    Home/Back/Menu Button
    Dedicated Emergency Button
  • Interface
    Nano-SIM Card Slot *1
    Micro-SD card slot *1
    Radio Grade Audio Interface *1
    Type-C USB 2.0 *1
    Desktop Charger Interface *1
  • Audio
    Specifications
  • Input
    Dual-Mic Noise Cancellation
  • Output
    2 Watt Built-in Speaker
  • Standard Accessories
    Specifications
  • USB Cable
    *1
  • Travel Charger
    *1
  • Battery
    *1
  • Quick Start Guide
    *1
  • Belt Clip
    *1
  • Standard Accessories
    Specifications
  • External Audio
    Remote Speaker Microphone
    PTT Earphone
    Airtube PTT Earphone
  • Power
    Desktop Charger
    Multi Unit Charger

M6P

  • Physical Characteristics
    Specifications
  • Dimension
    198.00mm x 70.00mm x 81.20mm
    7.8 in x 2.76 in x 3.2 in
  • Weight
    442g /15.6oz
  • Environmental
    Specifications
  • Dust And Water Intrusion
    IP54
  • Working temperature
    -20 to +60°C
  • PLATFORM & HARDWAR
    Specifications
  • Operating System
    Android Q
  • Processor
    2.2GHz Octa-core 64-bit Processor
  • Memory
    3GB RAM
    32GB Internal Storage
    Storage is expandable with external
    128 GB microSD™ card
  • Memory
    3GB RAM
    32GB Internal Storage
    Storage is expandable with external
    128 GB microSD™ card
  • Screen
    5.0-inch HD IPS Anti-Glare Screen
  • Touch Panel
    LCD Bonded 5 points Capacitive, support wet fingers, glove operation
  • Power Supply
    DC 12-24V wet fingers, glove operation
  • Sensor Platform
    Gravity Sensor
    Ambient Light Sensor
    Distance Sensor
    Geomagnetic Sensor
    Acceleration Sensor
  • CONNECTIVITY
    Specifications
  • VoLTE, ViLTE & VoWiFi
    Support*
  • PTT
    Support PTT apps & MCPTT QCI's 65, 66,69 &70
  • 3GPP Release
    Rel 13① 66,69 &70
  • WLAN
    IEEE 802.11 a/b/g/n/ac 2.4G+5G (Antenna needs to be connected) 66,69 &70
  • Bluetooth
    5.0 + LE +BR/EDR (Antenna needs to be connected) 66,69 &70
  • Location
    GPS+AGPS , GLONASS
    (Antenna needs to be connected)
  • INTERACTION & INTERFACE
    Specifications
  • Man Machine Interface
    Power Button
    Dedicated PTT Button (P1)
    Channel Switch & Volume+/- Knob
    Programmable Buttons
    SOS Button
  • nterface
    Micro-SIM card slot
    Micro-SD card slot (Up to 128GB)
    10Pin aviation interface
    Type-C USB 2.0
    USB-A
    3.5mm audio interface
    3Pin power interface
    DB9 interface
    Antenna interfaces
  • AUDIO
    Specifications
  • Input
    Dual-Mic with Noise Cancellation
    Independent Noise Cancellation chip
  • Output
    5Watt Built-in Speaker
