TRG-900
Repeater & Gateway
Repeater & Gateway 2-In-1
Combined DMR repeater and DMR-POC gateway, TRG-900 offers reliable radio service and stable gateway function simultaneously.
High Power
High Power
Maximum 50Watt transmit power, offering excellent coverage.
Smart OS
Smart OS
Plenty of 3rd party applications supported by Smart Android 8.1 operating system.
Expansion Ports
Expansion Ports
Multiple expansion ports offer superb extensibility.
Diversified Connection
Diversified Connection
TRG-900 supports LTE, WIFI and Ethernet, always connected with diversified connection.
IP Connect
IP Connect
Different sites can be connected by IP network.
Clusters Connections
Core
CPU Dual-core Cortex-A72 & Quad-core Cortex-A53
RAM 2GB DDR3
ROM 16 GB Emmc 5.1
Display 4.3¨ Inch IPS 800*480
Touch Screen 5 Points Multi-touch
Micro SD Card Up to 256GB
Battery 30Ah (Optional)
Radio Standard Digital mobile radio (DMR), Analog
Narrowband frequency range
VHF: 136-174MHz
UHF: 350-400MHz ; 400-470MHz
Channel Spacing 12.5KHz/20KHz/25KHz
Modulation FDMA/TDMA
Duplexer Spacing
VHF: 5.3MHz
UHF: 10MHz
Modulation and demodulation 4FSK/FFSK/FM
Frequency stability ±0.5ppm
Transfer rate 9.6kbps
Connectivity
LTE-FDD B1/B2/B3/B4/B5/B7/B8/B12/B13/B26/B18/B19/B20/B28
LTE-TDD B38/B39/B40/B41
3G B1/B2/B4/B5/B8/B6/B19
2G B2/B3/B5/B8
WIFI 2.4G 5G
Bluetooth 4.0 BLE
GPS Optional
Physical
Dimensions(include antenna and handle) 86*264*358mm(H*W*D)
Weight 6.9kg(without battery)
Receiver
Static sensitivity 0.3 uV/BER5%
Block 84 dB
Adjacent channel selectivity
-65 dB@12.5KHz
-70 dB@25KHz
Intermodulation 70 dB
Spurious response suppression
⩽-36dBm @ 100KHz @ 9.00-1.00GHz
⩽-30dBm @ 1.0MHz @1.00-12.75GHz
Transmitter
RF Power Output ⩽50W(Adjacent)
Modulation accuracy
⩽5.0%(Normal)
⩽10.0%(Extreme)
Adjacent channel power ⩽60dB (12.5kHz)
Spurious response suppression
⩽-36dBm @ 100KHz @ 9.00-1.00GHz
⩽-30dBm @ 1.0MHz @1.00-12.75GHz
Interface
USB Host USB 2.0
Type-C TYPE-C
HMDI HDMI2.0
Ethernet RJ45
